reverse flow smoker blueprint

* DIGITAL PRODUCT- PDF DOWNLOAD

This product is a plan to help you build a smoker. You are not purchasing the smoker itself.

30 x 68 in Propane Tank Hybrid Smoker Plans, Square Firebox Left, Square Warming Cabinet

$79.00
$79.00
Plans for a hybrid smoker built from a 30 in diameter propane tank, 68 in long, with...

Will my tank fit these plans?

These plans are drawn around a 30 in diameter tank that is at least 68 in long.

Your tank will work if it measures about 28.5 to 31.5 in across and is 68 in long or longer.

If your tank is inside this range but not an exact match, you just adjust a few cut lines. If you need help, let us know by replying to your order confirmation email.

How to measure your tank, plus common tank sizes
  • Diameter: wrap a tape around the tank and divide by 3.14. Most people guess the diameter and guess wrong.
  • Length: measure end to end, tip to tip.
TankDiameterLength
120 gallon24 in68 in
250 gallon30 to 31.5 in87 to 94 in
320 to 330 gallon30 in115 to 120 in
500 gallon37 to 38 in117.5 to 120 in
500 gallon, short41 in104 in
1000 gallon41 in188 to 194 in
420 lb upright30 in54 in tall

Sizes vary a little from one tank maker to the next. These come from published tank maker spec sheets.

Not sure? Enter your tank size on Find My Plan to see every plan that fits it, or email your tank measurements to admin@smokerplans.net before you buy, and we'll tell you which plan fits.

Building the cart too? Add those plans now, $50.

Each comes as its own download with your order.

reverse flow smoker blueprint

30 x 68 in Propane Tank Hybrid Smoker Plans, Square Firebox Left, Square Warming Cabinet

$79.00

30 x 68 in Propane Tank Hybrid Smoker Plans, Square Firebox Left, Square Warming Cabinet

$79.00
Building it on a trailer? Add the 3500 lb trailer plans sized for this smoker, $50: No thanks
